TLV3502 Dual Channel High Speed Comparator Module 4.5ns Delay Time
Tax included.
Description:
The TLV3502 is a single-channel, high-speed, push-pull output comparator with 4.5 ns delay and supply voltages of + 2.7V to + 5.5V,
making it ideal for low voltage applications with a wide range of input common-mode range. Rail-to-rail output can directly drive
CMOS or TTL logic. This module can shape the cycle signal of wide voltage range to be the front-end conditioning module for time
domain measurement such as frequency and phase difference.
Application:
1. Sine wave to square wave
2. Zero-crossing comparator
3. Universal comparator
Technical indicators:
1. Supply voltage: 2.7-5VDC
2. Input voltage: 10-1000mV (RMS)
3. Output Level: Rail-to-rail output, can be directly driven TTL / CMOS level
4. Input frequency: DC - 200MHz
5. Interface Type: SMA female (male screw hole)
6. Input impedance: 50 ohms
7. Shielding shell
Package included:
1 x TLV3502 Dual Channel High Speed Comparator Module
The TLV3502 is a single-channel, high-speed, push-pull output comparator with 4.5 ns delay and supply voltages of + 2.7V to + 5.5V,
making it ideal for low voltage applications with a wide range of input common-mode range. Rail-to-rail output can directly drive
CMOS or TTL logic. This module can shape the cycle signal of wide voltage range to be the front-end conditioning module for time
domain measurement such as frequency and phase difference.
Application:
1. Sine wave to square wave
2. Zero-crossing comparator
3. Universal comparator
Technical indicators:
1. Supply voltage: 2.7-5VDC
2. Input voltage: 10-1000mV (RMS)
3. Output Level: Rail-to-rail output, can be directly driven TTL / CMOS level
4. Input frequency: DC - 200MHz
5. Interface Type: SMA female (male screw hole)
6. Input impedance: 50 ohms
7. Shielding shell
Package included:
1 x TLV3502 Dual Channel High Speed Comparator Module
