EAI 360 Scanning Ultra-small Laser Radar 8 Meters Detector YDLIDAR X2L ROS Vehicle Navigation Path Planning Obstacle Avoidance
Tax included.
Description:
YDLIDAR X2L is a 360-degree two-dimensional rangefinder (hereinafter referred to as X2L) developed by YDLIDAR team. Based on the principle of triangulation, it is equipped with related optics, electricity, and algorithm design to achieve high-frequency and high-precision distance measurement. The mechanical structure rotates 360 degrees to continuously output the angle information as well as the point cloud data of the scanning environment while ranging.
Features:
-360 degree omnidirectional scanning ranging distance measurement
- Small distance error,stable performance and high accuracy
-Ranging distance is no less than 8m
- Strong resistance to ambient light interference
- Low power consumption, small size and long life
- Laser power meets Class I laser safety standards
- Adjustable motor speed(7HZ recommend)
-Ranging frequency up to 3kHz (support customization)
Applications:
Applications:
-Robot navigation and obstacle avoidance
-Robot ROS teaching and research
-Regional security
-Environmental scanning and 3D reconstruction
-Commercial robot /Robot vacuum cleaner
Package Included:
1 x Radar sensor
1 x USB cable
1 x Transfer module
Details Pictures:
