WESTBIG 1.8Inch TFT Touch Screen Full Color 128x160 SPI For Raspberry Pi
Tax included.
Size Conversion
Inches
Centimeters
Please according to your own measurements to choose your suitable size. The tags inside the items will show in our Asian (Type) size.
Features:
??/b>
??/b>
Display mode -TFT
The input data SPI interface
Drive IC ST7735S
Resolution 128RGB * 160 points
Active area LCD 28.03 (W) * 35.04 (H)
Pixel size 0.219 (W) * 0.219 (H)
Display direction At 12 o'clock
Operating temperature -20 70 ° C
Pin descriptions:
??/div>
??/div>
PIN No Symbol Description
1 GND Soil
2 VDC Power 3.3 V
3 SCL Series watch pin
4 SDA Data Entry Series
5 RES LCM Reset pin
This pin is resetting the signal input. When the pin is low, the initialization of the chip is
Executed! Keep this bolt high during normal operation.
6 DC Data / Control
7 CS Chip, select
8 BLK Control pin background
??br>?ŠPackage Included:
??br>??*Screen Module
??br>?ŠPackage Included:
??br>??*Screen Module
